RAPC10U, ST10U Product Bulletin Datasheet by Switchcraft Inc.

5555 N ELSTON AVE | CHICAGO, IL 60630 | P: 773.792.2700 | F: 773.792.2129 | WWW.SWITCHCRAFT.COM

SEALED UNMATED POWER JACKS

NPB | 608

PLEASE VISIT WWW.SWITCHCRAFT.COM FOR THE MOST UP-TO-DATE PRODUCT SPECIFICATIONS.

MADE IN USA

NPB | 608

FEATURES & BENEFITS

• Upto13Acurrentrating(carry)

• Upto24VAC/DC

• Availableinsealedonlybutcanbeused

 withS10styleplugsbothsealedand

 non-sealed

• Recommendpluglockingversionsto

 keepplugsconnectedtojack.

APPLICATIONS

• Anysealeddatatransmission

• MilitaryorindustrialGPSlocationdevices

• Instrumentation

• Medicalequipment

• MarineApplications

• Transportation

• Generalindustrialelectronicapplications

• Powersupplies

SEALED UNMATED POWER JACKS

s/vsxzuNEnA \ ;~ n 32010 003 x v H Ex \ - - aassm ‘40 CHEM R[' we ms ’ Juan: 7 , WWW m] , / W mm m w smmm hm 2pm on; REV W REV — ”1” mos j n ‘7[ ‘— T / m m 0:1 mg n) m 1071 1 SEALED llNMATEl] POWER JACK, RIGHT ANGLE - ORDERING CUBE: RAPMUH rigmnnm 737:00x wawmur wEwED no» snow :w m ’ us» an; m m aqizmoom “1:00! j \ nxsmaanx mim 1 PANLmew mwm mm Mom M; m “I” mm 6006) zir "'7l15n] mm m 2m; has} 5/15 31 UNLF u WWW an: w mu} mm was; m 1 an Sunni" L952] —4i smiMAnc coin w W j ‘ W: m M W W \s ‘3 ‘ m ‘7 m. [m]

PLEASE VISIT WWW.SWITCHCRAFT.COM FOR THE MOST UP-TO-DATE PRODUCT SPECIFICATIONS.

MADE IN USA

UNITSARELISTEDININCHES.ALLDIMENSIONSAREREFERENCEONLY.

NPB | 608

SEALED UNMATED POWER JACK, STRAIGHT - ORDERING CODE: ST10U

SEALED UNMATED POWER JACK, RIGHT ANGLE - ORDERING CODE: RAPC10U

SEALED UNMATED POWER JACK, STRAIGHT - ORDERING CODE: ST10U

SEALED UNMATED POWER JACK, RIGHT ANGLE - ORDERING CODE: RAPC10U

SEALED UNMATED POWER JACKS

PLEASE VISIT WWW.SWITCHCRAFT.COM FOR THE MOST UP-TO-DATE PRODUCT SPECIFICATIONS.

MADE IN USA

MECHANICAL SPECIFICATIONS

Life:     5000mechanicalcyclesminimumusingS10styleplugs

Vibration:    Mil-Std202GMethod201A(jackorwhenmatedwithlockingplug)

OperatingForces:   3lbmaximuminsertion

     0.2lbminimumwithdrawalwhenusingS10typleplug

PanelMountTorque:   8-10in/lb

ELECTRICAL SPECIFICATIONS

VoltageRating:   24VAC/DC

CurrentRating:   Refertocurrentratingtable

InsulationResistance:   1000MΩminimuminitial

ContactResistance(Initial):  10mΩmaximum

ENVIRONMENTAL SPECIFICATIONS

OperaingTemperatureRating:  -40°Cto+105°C(-40ºFto+221°F)

MoistureResistance:   Mil-Std202GMethod106G(jackorwhenmatedwithsealedlockingplug)

InsulationResistance:   Mil-Std202GMethod302(ConditionBOnly)

ThermalShock:   Mil-Std202GMethod107G(jackorwhenmatedwithsealedlockingplug)

SaltAtmosphere(Corrosion):  Mil-Std202GMethod101EConditionB

WeathertightRatings:   IP66,IP67,IP68,NEMA250(6P)(jackorwhenmatedwithsealedlockingplug)

MATERIAL SPECIFICATIONS

Housing,HexNut:   CopperAlloy,NickelPlated

Washer:    Steel,NickelPlated

Insulator:    Thermoplastic,Black

O-Ring:    Elastomer,Black

InternalO-Rings:   Elastomer,Amber

CenterPin:    CopperAlloy,GoldoverSilverPlated

CenterPin&ShuntTerminals:  CopperAlloy,MatteTinPlated

SleeveSpringContact:   CopperAlloy,GoldoverSilverPlated

SPECIFICATIONS

CURRENT RATING TABLE WHEN MATED TO S10 STYLE PLUGS

NPB | 608

Wire

(awg)

CurrentRating(A)atOperatingTemperature(°C)

90°Cmax 95°Cmax 100°Cmax 105°Cmax

16 13 12 11 10

18 12 11 10 9

20 11 10 98

Note:DCPowerPlugs&Jacksareforcurrentcarryingonly.Donotconnectordisconnectunderload.Thecircuitryon-offswitchshouldbeoff

beforeconnectinganddisconnectingthePowerPlugtotheJack.Ifwatergetsinthejack,itmaycauselowimpedancebetweencontactsbutthe

waterwillnotgetinsideyourproductifmountedproperly.Blowthewateroutofthejackandletdry,theimpedancewillreturntonormal.
