SERIES: VOF-10 │ DESCRIPTION: AC-DC POWER SUPPLY
PART NUMBER KEY
VOF-10 - XX
Base Number Output Voltage
FEATURES
• up to 10 W continuous power
• compact size
• universal input (85~264 Vac / 120~375 Vdc)
• single output from 3.3~48 Vdc
• no minimum load required
• 3000 Vac isolation
• over current, over voltage, and short circuit protections
• UL/cUL and TUV 60950-1 safety approvals
• no load power consumption < 0.5 W
• efficiency up to 78%
RoHS
MODEL output
voltage
output
current
output
power
ripple1
and noise
efficiency
(Vdc)
max
(A)
max
(W)
max
(mVp-p)
typ
(%)
VOF-10-3.3 3.3 2.4 8 100 70
VOF-10-5 5 2.0 10 100 75
VOF-10-9* 9 1.11 10 120 75
VOF-10-12 12 0.83 10 120 75
VOF-10-15 15 0.67 10 150 75
VOF-10-24 24 0.42 10 240 78
VOF-10-48* 48 0.21 10 480 78
Notes: 1. Ripple & noise are measured at 20 MHz BW with 47 µF ceramic and 100 nF electrolytic capacitors on the output
*. Discontinued.
Additional Resources: Product Page | 3D Model
Product Page 30 Model
cui.com
CUI Inc │ SERIES: VOF-10 │ DESCRIPTION: AC-DC POWER SUPPLY date 12/29/2015 │ page 2 of 5
INPUT
parameter conditions/description min typ max units
voltage 85
120
264
375
Vac
Vdc
frequency 47 63 Hz
input current 0.6 A
inrush current 110 Vac, full load, cold start
220 Vac, full load, cold start
15
30
A
A
input fuse built-in, non-user serviceable
OUTPUT
parameter conditions/description min typ max units
line regulation 3.3 Vdc model
all other models
±0.6
±0.5
%
%
load regulation 3.3 Vdc model
all other models
±1.2
±1
%
%
temperature coefficient ±0.05 %/°C
hold-up time at 115 Vac, full load 16 ms
adjustability adjustable with built-in trim pot ±5 %
switching frequency 100 kHz
no load power consumption 48 Vdc model
all other models
0.7
0.5
W
W
PROTECTIONS
parameter conditions/description min typ max units
over voltage protection clamped by TVS
over current protection automatically recovers 105 %
short circuit protection protected, long term short circuit may reduce
reliability
SAFETY & COMPLIANCE
parameter conditions/description min typ max units
isolation voltage input to output at 10 mA for 1 minute 3,000 Vac
isolation resistance input to output at 500 Vdc at 25°C 50 MΩ
safety approvals TUV EN 60950, UL/cUL 60950-1
EMI/EMC FCC class B, EN 55022 class B, CE
leakage current 0.25 mA
RoHS 2011/65/EU
MTBF according to MIL-HDBK-217F 250,000 hours
ENVIRONMENTAL
parameter conditions/description min typ max units
operating temperature see derating curve 0 60 °C
storage temperature -20 85 °C
operating humidity non-condensing 20 90 %
storage humidity non-condensing 20 90 %
Additional Resources: Product Page | 3D Model
Product Page 30 Model
100
an
60
40
20
Convecuon
Lead Vacmr ("/a)
U 10 20 3D 40 50 60 70
Ammem (emperamre( c)
cui.com
CUI Inc │ SERIES: VOF-10 │ DESCRIPTION: AC-DC POWER SUPPLY date 12/29/2015 │ page 3 of 5
MECHANICAL
parameter conditions/description min typ max units
dimensions 65 x 45 x 18.5 (2.56 x 1.77 x 0.73 inches) mm
cooling method free air convection (see derating curve below)
DERATING CURVES
MOUNTING METHOD
Horizontal
(performance evaluations conducted under this mounting method)
Additional Resources: Product Page | 3D Model
[ ]
+
H H I:
°_4&_=F
[ ]
t +
E
(VG
((-33
cui.com
CUI Inc │ SERIES: VOF-10 │ DESCRIPTION: AC-DC POWER SUPPLY date 12/29/2015 │ page 4 of 5
MECHANICAL DRAWING
18.5 0.728
1.0
+Vo
0.3749.5
0.1
54.5
0.413
0.1
12.5
0.1
10.5
0.492
0.1(2 PLCS)
2.146
0.043
1.1
(4 PLCS) 0.1
1.772
1.0
45.0
65.02.559
1.0
7.50.295
0.1
N
L
GND
0.039
1.0
(4 PLCS)
8.00.315
(4 PLCS)
units: mm [inches]
tolerance: ±0.3 [±0.01]
unless otherwise noted
Additional Resources: Product Page | 3D Model
Product Page 30 Model
CUI Inc │ SERIES: VOF-10 │ DESCRIPTION: AC-DC POWER SUPPLY date 12/29/2015 │ page 5 of 5
